class: center, middle # Vertical and Horizontal Scaling __CS291A__ Dr. Bryce Boe October 17, 2017 --- # Today's Agenda * TODO * [Complete Server Architecture Slides](/slides/2017/05_web_and_application_servers/#32) * Server Architecture Review * Motivation * Vertical Scaling * Horizontal Scaling --- # TODO ## Should be done * Chapters 1, 2, 9-11 in [HPBN](https://hpbn.co/primer-on-latency-and-bandwidth/) / Chapters 1-6 in the [Ruby on Rails Tutorial](https://www.railstutorial.org/book/beginning) * Familiarity with Git (you'll get more practice) * [Dynamic Load Balancing on Web-server Systems](http://www.ics.uci.edu/~cs230/reading/DLB.pdf) by Cardellini, Colajanni, and Yu. ## Before Thursday's Lab * Complete at least #TEAM_MEMBERS stories that deliver value to your users (me). * Complete chapters 7 through 10 in the [Ruby on Rails Tutorial](https://www.railstutorial.org/book/beginning) * Hook TravisCI up to your repository. __Focus__: On delivering new usable features to your customers (me) for the next few weeks. --- # HTTP Server Architecture Review * Single Threaded (no concurrency) * Process per request * Process pool * Thread per request * Process/thread worker pool * Event-driven --- class: center, middle # What are the trade-offs of process-based concurrency? --- class: center, middle # What are the trade-offs of thread-based concurrency? --- class: center, middle # What are the trade-offs of event-driven systems? --- # Scaling Goal .center[![Load Balanced Topology](load_balanced_topology.png)] After today you will understand what load balancing is, and why the depicted architecture provides smooth cost-effective scaling. --- # The Problem You've built something the world (or significant subset) is excited about. > What do you do when your popularity doubles (again, and again)? --- # The Solutions ## Vertical Scaling Buying "bigger" hardware and scaling _up_ * __PRO__: Easy * __CON__: Limited * __CON__: Non-linear increase in cost when scaling -- ## Horizontal Scaling Buying move servers and scaling _out_ * __PRO__: Easy to add more servers (limited by data center space) * __PRO__: Linear (maybe even sublinear) increase in cost when scaling * __CON__: More moving parts makes things more complicated --- # Vertical Scaling When needed, increase the resources of your current server, eventually buy a bigger server with: * More memory * More and/or faster CPUs and/or cores * Higher bandwidth --- # EC2 and Vertical Scaling With Amazon EC2 you rent virtual instances. There are clear vertical scaling paths. Each type of instance (below) has a few options ranging from lower resources/performance to higher resources/performance: * __T__ and __M__ prefixed instances: balanced mix of memory and CPU * __C__ prefixed instances: CPU optimized * __R__ prefixed instances: Memory optimized * __G__ prefixed instances: GPU optimized * __I__ prefixed instances: I/O optimized * __D__ prefixed instances: Storage capacity optimized --- # Scaling Test: Simulated Users We will use the same test setup explained in the last lecture. Using Tsung (erlang-based test framework) we will simulate multiple users visiting the Demo App web service. Each user will: ``` Visit the homepage (/) Wait randomly between 0 and 2 seconds Request community creation form Wait randomly between 0 and 2 seconds Submit new community form Request new link submission form Wait randomly between 0 and 2 seconds Submit new link submission form Wait randomly between 0 and 2 seconds Delete the link Wait randomly between 0 and 2 seconds Delete the community ``` --- # Scaling Test: Phases This time we have twelve phases of testing each lasting 60 seconds: ``` 1. (0-59s) Every second a new simulated user arrives 2. (60-119s) Every second 1.5 new simulated users arrive 3. (120-179s) Every second 2 new simulated users arrive 4. (180-239s) Every second 4 new simulated users arrive 5. (240-299s) Every second 6 new simulated users arrive 6. (300-359s) Every second 10 new simulated users arrive 7. (360-419s) Every second 16 new simulated users arrive 8. (420-479s) Every second 20 new simulated users arrive 9. (480-539s) Every second 25 new simulated users arrive 10. (540-599s) Every second 35 new simulated users arrive 11. (600-659s) Every second 45 new simulated users arrive 12. (660-719s) Every second 55 new simulated users arrive ``` --- # Vertical Scaling: M3 Large Instance .left-column20[ * 2 vCPUs * 7.5 GB Memory * SSD storage * $100 per month Handles 6 new users per second (ups). Fails with 10 ups. ] .right-column80[ ![M3 Large Instance Graph](vertical_scaling_m3_large.png) ] --- # Vertical Scaling: M3 X-Large Instance .left-column20[ * 4 vCPUs * 15 GB Memory * SSD storage * $200 per month Handles 10 new users per second (ups). Fails with 16 ups. ] .right-column80[ ![M3 X-Large Instance Graph](vertical_scaling_m3_xlarge.png) ] --- # Vertical Scaling: M3 XX-Large Instance .left-column20[ * 8 vCPUs * 30 GB Memory * SSD storage * $400 per month * Largest available M-prefixed instance. Handles 16 new users per second (ups). Fails with 20 ups. ] .right-column80[ ![M3 XX-Large Instance Graph](vertical_scaling_m3_xxlarge.png) ] --- # Vertical Scaling: C3 4XLarge Instance .left-column20[ * 16 vCPUs * 30 GB Memory * SSD storage * $600 per month Handles 20 new users per second (ups). Fails with 25 ups. ] .right-column80[ ![C3 4XLarge Instance Graph](vertical_scaling_c3_4xlarge.png) ] --- # Load Balancing Vertical scaling has its place, but horizontal scaling is generally preferable. When horizontally scaling HTTP, this technique is referred to as __load balancing__. ## Basic Idea * Have many servers that can serve clients * Make these servers _appear_ as a single endpoint to the outside world The users' experiences are the same regardless of which server ultimately handles the request. --- # Think About It > How can we enable many servers to serve clients? Consider the following sequence of actions: 1. `GET /products` 2. `POST /products` 3. `GET /products` > If these requests are handled by three different servers, will the third > request show the new product? --- # Stateless Servers .center[![Load Balanced Topology](load_balanced_topology.png)] In order for load balancing to work, the servers must be stateless. Statelessness can be accomplished by keeping the persistence layer separate from the application layer. --- # Load Balancing (1): HTTP Redirects .left-column30[ Discussed in section 6.1 of the reading. Implemented using multiple web servers with different domain names. A request for `www.domain.com` will use HTTP 301 or 302 to redirect the request to a pool of possible hosts. ] .right-column70.center[ ![Load balancing via redirect](load_balancing_redirect.png) ] --- # HTTP Redirect Example ```http % nc www.domain.com 80 GET / HTTP/1.1 host: www.domain.com HTTP/1.1 301 Moved Permanently Date: Wed, 15 Oct 2014 21:08:22 GMT Server: Apache/2.2.22 (Ubuntu) Location: http://www2.domain.com/ Content-Type: text/html; charset=iso-8859-1 ... ``` --- # HTTP Redirects Trade-offs ## Strengths * Simple * Complete control over load balancing algorithm * Location independent ## Weaknesses * Not transparent to user * High load on www * May reduce local-network cache applicability --- # Load Balancing (2): Round Robin DNS .left-column30[ Discussed in section 4.1 of the reading. When a user's browser queries DNS for `www.example.com`, a list of IPs is returned. The DNS server rotates the list order for each query (or alters priorities). The user's browser chooses which IP to connect to (generally picks the first, or highest priority). ] .right-column70.center[ ![Load balancing via round-robin DNS](load_balancing_round_robin.png) ] --- # Round Robin DNS Example ``` % host cs291.com cs291.com has address 192.30.252.153 cs291.com has address 192.30.252.154 ``` ``` % host cs291.com cs291.com has address 192.30.252.154 cs291.com has address 192.30.252.153 ``` --- # Round Robin DNS Trade-offs ## Strengths * Simple * Cheap ## Weaknesses * Less control over balancing * Modifying the list is inhibited by caching in the browser and proxies --- # Load Balancing (3): TCP Load Balancing .left-column30[ Discussed in section 5 of the reading. ## General Idea Rewrite TCP packets to send them to the selected server. This includes addresses, sequence numbers, and checksums. ] .right-column70.center[ ![Load balancing via TCP](load_balancing_tcp.png) ] ## Commercial Products (use hardware ASICs to do this fast) * Cisco Content Services Switch * Citrix Netscaler * F5 Big IP --- # TCP Load Balancing HTTP Request ``` (client -> lb) IP D=208.50.157.136 S=216.64.159.149 LEN=60, ID=48397 TCP D=80 S=1421 Syn Seq=899863543 Len=0 Win=32120 (lb -> server) IP D=10.16.100.121 S=208.50.157.136 LEN=60, ID=48397 TCP D=80 S=1421 Syn Seq=899863543 Len=0 Win=32120 (server -> lb) IP D=208.50.157.136 S=10.16.100.121 LEN=48, ID=26291 TCP D=1421 S=80 Syn Ack=899863544 Seq=1908949446 Len=0 (lb -> client) IP D=216.64.159.149 S=208.50.157.136 LEN=48, ID=26291 TCP D=1421 S=80 Syn Ack=899863544 Seq=1908949446 Len=0 (client -> lb) IP D=208.50.157.136 S=216.64.159.149 LEN=154, ID=48401 TCP D=80 S=1421 Ack=1908949447 Seq=899863544 Len=114 HTTP GET /eb/images/ec_home_logo_tag.gif HTTP/1.0 (lb -> server) IP D=10.16.100.121 S=208.50.157.136 LEN=154, ID=48401 TCP D=80 S=1421 Ack=1908949447 Seq=899863544 Len=114 HTTP GET /eb/images/ec_home_logo_tag.gif HTTP/1.0 ``` --- # TCP Load Balancing HTTP Response ``` (server -> lb) IP D=208.50.157.136 S=10.16.100.121 LEN=1500, ID=22237 TCP D=1421 S=80 Ack=899863658 Seq=1908949447 Len=1460 HTTP HTTP/1.1 200 OK (lb -> client) IP D=216.64.159.149 S=208.50.157.136 LEN=1500, ID=22237 TCP D=1421 S=80 Ack=899863658 Seq=1908949447 Len=1460 HTTP HTTP/1.1 200 OK ``` --- # TCP Load Balancing Trade-offs ## Strengths * More control over which requests go to which servers * Works fine with HTTPs ## Weaknesses * Limits where the servers can be located (same network) * Complicated --- # Load Balancing (4): HTTP Proxy .left-column30[ Also known as "Layer 7 load balancing" Terminate HTTP requests: act like a web server Issue _back-end_ HTTP request to the desired application server. Hardware products: * Citrix Netscaler * F5 Big-IP Many HTTP servers have modules to do this as well (Apache, NGINX) ] .right-column70.center[ ![Load balancing via TCP](load_balancing_http_proxy.png) ] --- # HTTP Proxy Trade-offs This is the most popular technique in use (#3 is also used). ## Strengths * Cleaner implementation than packet rewriting ## Weaknesses * Load balancer needs to do more work * HTTPs is more complicated --- # Load Balancing Considerations Assume you are to design a load balancing HTTP proxy. You have insight into every incoming request and response. > How would you determine which server to forward a request to? -- ## Options * Random * Round robin * Least number of connections * Fastest response time * Bandwidth per server * URI-based mapping (e.g., `/images` to server1, `/admin` to server2) Amazon's ELB (elastic load balancer) uses round robin with cookie-based stickiness (send the same client to the same server). --- # Load Balancing Challenges When working with and/or designing a load balancing proxy there are some challenges to consider: * Detecting and reacting to server failures * Session affinity and persistence * Connection pooling Definitions: * __Affinity__: Map a client to a server without application-level information (e.g., IP address, request time) * __Persistence__: Use application-level information to map a client to a server (e.g., cookies) [Reference](https://www.haproxy.com/blog/load-balancing-affinity-persistence-sticky-sessions-what-you-need-to-know/) --- # Detecting Server Failures > How do we know when a member of our application pool has died? Observe traffic. Are requests being processed? Are they just taking a long time? Probe the server through various means: * __ICMP ping__: tests the network and server kernel * __TCP connection__: the process is running and accepting connections * __HTTP HEAD__: the application is serving pages * __SNMP__: Provides insight into server load (and more if configured) --- # Session Affinity and Persistence > Can we redirect users back to the same web server they used before? Doing so can provide some caching improvements. A few options: * Affinity based on client IP address (concerns: client IPs change, and IPs are shared) * HTTP Cookie (works but requires proxy configuration) * Session ID in URL (not a great solution) --- # Connection Pooling We're used to the idea that one client reuses a TCP connection for many HTTP requests. We can reuse this mechanism for distinct clients. Saves on repeated TCP setup between the load balancer and application servers. Reduces idle waiting on server for reads and writes. --- # Software Load Balancers * Apache * NGINX * HAProxy * Varnish * Pound * Squid --- # Amazon Elastic Load Balancer Amazon provides load balancing as a service: * $0.025 per load balancer hour * $0.008 per GB of data processed * Works with EC2 autoscaling groups * Supports TLS termination * Supports load balancing between Availability Zones within a Region __Does not__: support load balancing between regions (e.g., between us-west-1 and us-west-2). Consider using Route 53 DNS for region failover. --- # Horizontal Scaling Test In the vertical scaling tests, the database application ran on the same machine as the web server application. For these tests we are going to use a single machine for the database. This will make it easy to scale up the number of application servers. .center[![Single Server Load Balanced Topology](load_balanced_topology_single.png)] --- # Horizontal Scaling: 1 M3 Large Instance .left-column20[ * 2 vCPUs * 7.5 GB Memory * SSD storage * DB is also M3 large * $200 per month ($100 each) Handles 10 new users per second (ups). Fails with 16 ups. Comparable to single M3 XLarge ($200/mo) ] .right-column80.center[ ![Single M3 Large Instance Graph](horizontal_scaling_1.png) ] --- # Adding an App Server Let's scale horizontally by adding a second application server instance. .center[![Dual Server Load Balanced Topology](load_balanced_topology_double.png)] --- # Horizontal Scaling: 2 M3 Large Instances .left-column20[ * 2 vCPUs * 7.5 GB Memory * SSD storage * DB is also M3 large * $300 per month ($100 each) Handles 20 new users per second (ups). Fails with 25 ups. Comparable to single C3 4XLarge ($600/mo) ] .right-column80.center[ ![Dual M3 Large Instance Graph](horizontal_scaling_2.png) ] --- # More App Servers! .left-column30[ Let’s see how the system performs if we scale out to 5 app servers. Total dollar cost will be comparable to the most expensive single instance we tested. ] .right-column70.center[ ![5x Load Balanced Topology](load_balanced_topology_5x.png) ] --- # Horizontal Scaling: 5 M3 Large Instances .left-column20[ * 2 vCPUs * 7.5 GB Memory * SSD storage * DB is also M3 large * $600 per month ($100 each) Handles 35 new users per second (ups). ] .right-column80.center[ ![Five M3 Large Instance Graph](horizontal_scaling_5.png) Single C3 4XLarge ($600/mo) failed at 25 ups! ] Handles 45 ups with an increase in response time. Fails with 55 ups. --- # Horizontal Scaling FTW! Vertical scaling handled only 20 new users per second at a cost of about $600 per month. There was no clear scaling path after that point. Horizontal scaling handled 45 new users per second at a cost of about $600 per month. The scaling path is clear. Add more servers for a linear increase in cost. _FTW_: For the Win --- # Load Balancing the Load Balancer From Github: http://githubengineering.com/introducing-glb/ From Facebook: https://www.youtube.com/watch?v=dKsOvc73gQk
